Why not revisit stream processing?
Brief Overview
When you think about real-time stream processing, one tool that often comes to mind is Apache Flink. It’s a powerful framework designed to handle unbounded and bounded data streams with remarkable efficiency. Let’s dive into what makes Apache Flink a standout solution for stream processing and how it differs from other tools like Apache Spark.
Understanding Unbounded and Bounded Data Streams
Apache Flink is a framework and distributed processing engine for stateful computations over unbounded and bounded data streams.
Before diving into Apache Flink’s capabilities, it’s crucial to establish a technical understanding of unbounded and bounded data streams:
Unbounded Data
Unbounded data refers to continuously generated streams without predefined boundaries. These streams do not have a known start or end point and require processing frameworks capable of handling data in real-time. For example, user interaction events on an active e-commerce platform represent unbounded data—new events continuously flow as long as the application remains operational. Managing unbounded data demands mechanisms for:
Stateful processing to retain context across events.
Low-latency computation for real-time insights.
Windowing techniques to segment infinite streams into finite, processable chunks.
Bounded Data
In contrast, bounded data streams have a finite size with clearly defined start and end points. These datasets are typically processed as discrete units or batches. Examples include daily exports of transactional records or historical data snapshots from operational databases. Handling bounded data often emphasizes:
Deterministic computation, as the data size is fixed.
Efficient batch execution models for optimized throughput.
Retry mechanisms for failed processing tasks.
Processing Paradigms
Apache Spark: Streamlines processing by treating stream data as a sequence of micro-batches. While effective for batch-oriented use cases, this design introduces latency in real-time applications.
Apache Flink: Adopts a unified approach where everything is treated as a stream, positioning bounded data as a special case of unbounded streams. This enables Flink to seamlessly handle real-time and batch workloads using the same underlying architecture. Its features include event-time processing, exactly-once state consistency, and high fault tolerance, making it ideal for diverse use cases.
Understanding these distinctions underscores Flink’s flexibility and power in delivering robust solutions for both unbounded and bounded data scenarios.
Why Apache Flink?
Apache Flink stands out as a robust framework for processing both unbounded and bounded data streams, offering unparalleled flexibility and performance for real-time and batch workloads. Its design is tailored for modern, data-intensive applications, making it the go-to choice in scenarios that demand low-latency processing, state management, and fault tolerance.
Real-Time Stream Processing
Flink excels in situations where real-time streams from sources like Apache Kafka, Google Cloud Pub/Sub, or Amazon Kinesis need to be consumed, transformed, and routed to downstream systems. By leveraging Flink’s rich APIs—available in Java, Scala, and Python—developers can define sophisticated applications with complex logic, including aggregations, joins, and windowing operations.
These applications can be deployed seamlessly across various cluster environments:
YARN for distributed resource management.
Kubernetes for containerized and scalable deployments.
Standalone setups for simpler, self-managed clusters.
Built for Stateful Computations
One of Flink’s most significant advantages is its ability to handle stateful computations effectively, which is critical for many complex, real-time use cases:
Fraud Detection: Monitor transaction streams to identify anomalous patterns in real-time, enabling quick responses to prevent fraud.
Recommendation Engines: Analyze user interactions and preferences dynamically to deliver personalized recommendations instantly.
Dynamic Pricing Models: Adjust prices in real-time based on supply, demand, and other external factors, such as competitor pricing or market trends.
Flink’s state management is powered by a robust checkpointing mechanism, ensuring exactly-once processing semantics, even in the face of failures. This makes it a reliable choice for mission-critical applications.
Unified Batch and Stream Processing
Unlike frameworks that treat batch and stream processing as separate paradigms, Flink unifies them under a single model. Bounded (batch) data is treated as a specific case of unbounded (stream) data. This unified approach allows Flink to handle diverse workloads without switching contexts or tools, enabling:
Real-time analytics on streaming data.
Batch processing for historical datasets.
Hybrid scenarios that combine real-time and batch data for comprehensive insights.
Advanced Features
Event-Time Processing: Handles late-arriving data effectively by processing events based on their timestamps, not arrival times.
Rich Connectors: Integrates with a wide range of systems, including relational databases, data lakes, and message brokers.
High Scalability: Can scale horizontally across clusters to handle increasing workloads effortlessly.
Fault Tolerance: Ensures consistent results even during system failures using distributed snapshots and recovery mechanisms.
Apache Flink Architecture
Apache Flink is a distributed processing engine built to handle both batch and stream data processing. Its architecture is designed for scalability, fault tolerance, and low-latency processing. A typical Flink setup includes several key components that work together to ensure the execution and management of Flink applications.
Key Components of Flink Architecture
1. Dispatcher
The Dispatcher is responsible for receiving application submissions and managing job execution. It provides a REST interface through which users can submit their Flink applications. Additionally, it runs a dashboard that displays information about job executions, including the status of jobs and job execution metrics.
2. JobManager
The JobManager is the master component responsible for managing the execution of Flink applications. It handles the scheduling and distribution of tasks to TaskManagers, manages job state, and performs operations such as checkpointing and recovery. Each Flink application has its own JobManager. The JobManager is also responsible for:
Managing the job’s lifecycle (e.g., starting, suspending, resuming).
Handling failure recovery by re-executing tasks or restoring state from checkpoints.
Coordinating task scheduling, including the parallel execution of tasks.
3. ResourceManager
Flink’s ResourceManager interacts with external resource providers, such as YARN, Kubernetes, or standalone clusters. It is responsible for managing TaskManager slots and coordinating resource allocation. Each resource provider may have a different ResourceManager that integrates with the cluster. The ResourceManager's responsibilities include:
Allocating TaskManager slots based on available resources and the requirements of the JobManager.
Communicating with the TaskManagers to manage their lifecycle and resource allocation.
Scaling the application dynamically by adding more TaskManagers when necessary (e.g., if the JobManager requests more slots than are available).
4. TaskManagers
TaskManagers are worker processes that perform the actual data processing tasks. Each TaskManager in a Flink setup provides a set of "slots," which are execution units that run Flink tasks. The number of slots per TaskManager is limited, and this limitation controls the concurrency of task execution in Flink. TaskManagers have the following responsibilities:
Executing tasks assigned by the JobManager.
Managing the state of the tasks during execution.
Reporting task status and metrics back to the JobManager.
Multiple TaskManagers can be deployed in a Flink cluster to scale the system horizontally. Each TaskManager can handle multiple tasks in parallel, with the number of tasks limited by the number of available slots.
In addition to the Dispatcher, JobManager, ResourceManager, and TaskManager, there are a few more components that are part of a typical Apache Flink setup. These components are crucial for the overall functioning and efficiency of Flink's distributed streaming and batch processing capabilities:
5. JobGraph
Function: Represents the directed acyclic graph (DAG) of operations that defines the structure of a Flink job.
Role: The logical execution plan, which is submitted by the user to Flink. This graph contains nodes representing operators (e.g., map, reduce, filter), and edges represent data flows between operators. The JobManager converts this logical JobGraph into a physical execution plan, considering parallelism and resource allocation.
6. Checkpoint Coordinator
Function: Coordinates the checkpointing process to ensure fault tolerance.
Role: The Checkpoint Coordinator ensures that the state of the running Flink job is periodically saved (i.e., checkpoints). This is essential for fault tolerance, as it allows Flink to recover from failures by restoring state from the most recent checkpoint.
7. Savepoint
Function: A user-triggered, consistent snapshot of a Flink job’s state.
Role: Savepoints are used for manually triggering state snapshots, typically for upgrades or scaling operations. Unlike checkpoints, which are automatic, savepoints are explicitly triggered by the user and can be used for job recovery.
8. State Backend
Function: Stores the state of a Flink job.
Role: The state backend is responsible for managing the job’s state, which can be accessed and updated by operators. Flink supports various state backends, such as the RocksDBStateBackend (for large-scale state management) or FsStateBackend (for simpler file-based state storage). The state backend is also responsible for persisting checkpoints and savepoints.
9. Task Slots
Function: Execution units where tasks are executed.
Role: Task slots define the degree of parallelism in TaskManagers. Each TaskManager has a number of available slots. A task is executed in a slot, and the number of tasks a TaskManager can execute is limited by the number of slots available.
10. Shuffle and Data Exchange
Function: Responsible for distributing data between operators.
Role: During execution, Flink needs to shuffle and exchange data between tasks, particularly when tasks need data from other partitions or tasks (e.g., in a join or aggregation). Flink has an optimized shuffle mechanism that allows for high-throughput, low-latency data exchanges.
11. Client
Function: An interface for users to submit and monitor jobs.
Role: The Flink Client is used to interact with Flink's job submission and monitoring systems. Clients can submit jobs, check the status of jobs, and retrieve information from the Flink cluster. It can be a command-line interface (CLI), a REST API, or a programmatic interface through a Flink client library.
12. Metrics and Monitoring System
Function: Provides insight into the performance and health of Flink jobs and resources.
Role: Flink has built-in support for metrics collection, such as task completion times, throughput, latency, and resource usage. These metrics can be integrated with external monitoring tools like Prometheus or Grafana, enabling real-time monitoring of Flink jobs and resources.
Typical Flow of a Flink Application
The typical flow of a Flink application involves several steps, with different components of the Flink architecture working together to ensure efficient, fault-tolerant, and scalable execution. Below is an expanded overview of the flow, explaining the role of each component and how they interact.
1. Application Submission
User Interaction: The user submits a Flink application to the Dispatcher using a REST interface or a command-line interface (CLI).
Dispatcher's Role: The Dispatcher is the entry point for job submission in the Flink architecture. It receives the application from the user, processes it, and forwards the job to the JobManager for execution.
Forwarding to JobManager: After receiving the job submission, the Dispatcher communicates with the JobManager to initiate the execution of the application.
2. JobManager Execution
JobGraph Creation: Upon receiving the application, the JobManager converts the logical JobGraph (representing the user's program) into a physical execution plan. The JobGraph consists of a directed acyclic graph (DAG) that defines the sequence of operations (e.g., map, reduce, filter) and their data flows.
JobManager's Role: The JobManager coordinates the execution of the job, determining how the tasks are scheduled, distributed, and executed across the cluster.
Physical Plan Generation: The JobManager takes into account available resources, parallelism, and other execution parameters when deciding how to implement the JobGraph in a physical execution plan.
3. TaskManager Allocation
Resource Request: The JobManager requests TaskManager slots from the ResourceManager to run the tasks that are part of the execution plan.
ResourceManager's Role: The ResourceManager is responsible for managing cluster resources. It communicates with external resource providers (e.g., YARN, Kubernetes) to allocate available resources for task execution.
Slot Allocation: The ResourceManager checks the available TaskManager slots and allocates them based on the requirements of the JobManager. Each TaskManager can provide a fixed number of slots for task execution.
Scaling: If there are insufficient available slots, the ResourceManager can trigger the addition of more TaskManagers to the cluster, scaling the system dynamically to meet the demands of the application.
4. Task Execution
Task Execution in TaskManagers: Each TaskManager executes a set of tasks (subtasks) assigned by the JobManager. The tasks are distributed across the available TaskManager slots, and each task runs within its own slot.
Parallel Execution: The TaskManager is capable of running multiple tasks in parallel, and the number of tasks it can handle is determined by the number of available slots.
Task Coordination: Tasks are managed and coordinated by the JobManager, ensuring that they are executed in the correct order and with appropriate parallelism.
5. State and Checkpoints
Checkpoint Coordination: The Checkpoint Coordinator periodically triggers checkpoints during the execution of the job. These checkpoints save the state of the application at specific intervals, ensuring fault tolerance.
State Management: The state of each task, including in-flight data, is stored periodically in checkpoints. Flink’s state backend is responsible for managing this state.
Fault Tolerance: If a failure occurs, Flink can restore the application’s state from the most recent checkpoint, allowing the job to resume execution from where it left off.
Savepoints: Savepoints are manually triggered snapshots of the application’s state, used primarily for upgrades or scaling. They are more controlled than regular checkpoints and allow for a clean, consistent state capture.
6. Task Coordination
Data Exchange via Shuffle: During the execution of the application, tasks often need to exchange data between one another, especially in operations like joins, aggregations, or repartitioning.
Shuffle Mechanism: Flink uses an optimized shuffle mechanism to efficiently distribute data between tasks. This ensures that the data flows smoothly between operators, maintaining high throughput and low latency.
Dynamic Task Rescheduling: Based on resource availability and parallelism, tasks can be dynamically rescheduled to different TaskManagers if needed. This enables Flink to adapt to changing workloads and resource conditions in the cluster.
7. Coordinating Checkpoints and Failure Recovery
Fault Recovery: The JobManager coordinates recovery from failures by re-executing failed tasks or restoring the state from the most recent checkpoint or savepoint.
JobManager’s Responsibility: In the event of a failure, the JobManager is responsible for detecting the failure, notifying the appropriate TaskManagers, and reassigning tasks if necessary. It may also restore the state of tasks to a consistent point to resume execution.
Visual Representation
A visual representation of the flow of a Flink application would depict the interactions between the components as follows:
Application Submission:
User submits the job → Dispatcher (via REST interface or CLI).
JobManager Execution:
Dispatcher forwards the job → JobManager (converts logical JobGraph into a physical execution plan).
TaskManager Allocation:
JobManager requests slots from the ResourceManager → ResourceManager allocates TaskManager slots → TaskManager (executes tasks).
If there are insufficient slots, the ResourceManager triggers scaling by adding more TaskManagers.
Task Execution:
TaskManager executes tasks in parallel using available slots.
State and Checkpoints:
Checkpoint Coordinator periodically triggers checkpoints for fault tolerance.
JobManager ensures recovery from checkpoints or savepoints in case of failures.
Task Coordination and Shuffle:
Shuffle mechanism exchanges data between tasks, maintaining efficiency.
JobManager coordinates parallelism and dynamic task rescheduling.
Parallelism and Task Execution
Flink allows parallel execution of tasks, providing high scalability and low-latency processing. The parallelism of each operator in the execution plan can be set individually, which determines the number of tasks (subtasks) that will be executed in parallel.
For example:
If an operator has a parallelism level of 4, it will spawn 4 tasks, each handling a portion of the data. These tasks are distributed across available TaskManager slots.
If a TaskManager has more slots available, it can handle more tasks, increasing the degree of parallelism and speeding up processing.
In a typical scenario, a Flink application may have a logical graph consisting of multiple operators, with each non-source/sink operator having a parallelism level of 4 (e.g., 4 tasks). If two TaskManagers are available, each with 2 slots, the TaskManager will handle 2 tasks at a time, distributing the load across available resources.
Example: Physical Graph with Four Operators
Consider a scenario where a Flink application involves four operators (excluding source and sink). If each operator has a parallelism level of 4 (i.e., 4 subtasks per operator), the physical execution plan will have 16 tasks in total. If there are two TaskManagers with two slots each, the TaskManagers will process the tasks as follows:
TaskManager 1: Processes 4 tasks (from 2 operators).
TaskManager 2: Processes 4 tasks (from 2 operators).
This setup allows the tasks to be executed in parallel, improving overall throughput and performance.
Parallelism and Task Execution
Flink achieves high throughput through its ability to run tasks in parallel. Consider a scenario with four operators, each configured with a parallelism level of 4. This setup creates 16 tasks in total.
Key Points About Parallelism:
TaskManagers and Slots: Each TaskManager provides a fixed number of slots, dictating how many tasks it can handle concurrently. For instance, two TaskManagers with two slots each can execute four tasks simultaneously.
Task Types: Tasks executed by a TaskManager can originate from:
The same operator, with data partitioned logically (e.g., by key).
Different operators within the same job.
Entirely separate jobs running on the cluster.
Below is a representation of how tasks are distributed across TaskManagers:
Data Processing Model in Flink
In Apache Flink, data processing is expressed through a dataflow programming paradigm, where the program is modeled as a directed graph. The nodes of this graph represent operators (functions that perform computations), while the edges represent data dependencies between these operators.
Dataflow Graph Structure
The dataflow graph can be viewed at two different levels:
Logical Graph: This is the high-level representation of the program. It shows the sequence of computations that need to be applied to the incoming data. The logical graph defines the structure of the computation, including the operators and their data flows, but it doesn’t specify how these computations will be executed.
Physical Graph: The physical graph is derived from the logical graph and describes how the program will be executed on the cluster. It includes details about operator placement, parallelism, task scheduling, and resource allocation. The physical graph represents the actual execution plan that the JobManager uses to schedule tasks on TaskManagers.
This separation between the logical and physical graphs allows Flink to optimize execution, abstracting the complexity of parallel processing and resource management from the user.
Types of Operations in Flink
Flink offers a wide variety of operations to handle data streams. These operations can generally be categorized by their statefulness and functionality.
1. Stateful vs Stateless Operations
Stateless Operations: These operations do not maintain any internal state between processing events. Each event is processed independently of others. Because of this independence, stateless operations are easier to parallelize and restart. These operations are commonly used for filtering, mapping, and flatMap transformations.
Stateful Operations: In contrast, stateful operations maintain some internal state between events. For example, an operation that calculates an aggregate function (like sum or count) will accumulate data over time. Stateful operations are more complex to parallelize because each instance of the operation must be aware of the global state or partitioned state. These operations require careful management to ensure correctness, especially when scaling or recovering from failures.
2. Functional Categories of Operations
Ingest: These operations consume input data from external sources (e.g., files, sensors, databases) or other operators. Ingest operations can read from streaming sources like Kafka, or batch sources like files, and feed data into the processing pipeline.
Egress: Egress operations produce output data. This could involve writing processed data to external systems like a database, file system, or messaging system.
Transformation: The transformation operations modify or process the incoming data. They include operations like map, flatMap, filter, and keyBy. Each transformation processes individual events or groups of events, applying a function that changes their structure or content.
Rolling Aggregation: This operation computes cumulative metrics, such as sum, count, min, and max, over a stream of events. It maintains state to store intermediate results and updates these aggregates with each incoming event. Since the aggregation depends on the historical state, this operation is inherently stateful. Windows are often used in conjunction with rolling aggregation to define the time period or set of events over which the aggregation occurs.
Window Operations: These operations handle unbounded streams by dividing them into finite windows. Windows allow the program to apply computations over specific subsets of the data, based on time or event characteristics. There are three different types of windowing strategies:
Fixed (Tumbling) Windows: In fixed windows, data is divided into non-overlapping chunks of fixed size. For example, a window might contain all data within a 5-minute interval. Each event is assigned to one window based on its timestamp.
Sliding Windows: Sliding windows are similar to fixed windows but with overlapping intervals. For instance, a sliding window with a 5-minute size and a 1-minute slide will contain all data from the last 5 minutes, but it will "slide" forward every minute, creating overlapping windows.
Session Windows: In session windows, data is grouped based on inactivity gaps between events. If no events arrive for a predefined period (the "inactivity gap"), a new window is started. For example, if a user does not interact with an app for 6 minutes, the system may create a new session window to represent this period of inactivity.
These windowing strategies help manage the unbounded nature of stream data by providing a way to group and analyze data within finite periods. Time semantics (event time, processing time, etc.) and state management are crucial to the correct execution of windowing operations.
Time Semantics and State Management
Time Semantics in Flink
In stream processing, handling time is essential because data may arrive out of order, and processing might happen at different times. Flink provides several types of time semantics to deal with these challenges:
Event Time: Event time refers to the timestamp embedded in the event itself, indicating when the event actually occurred. This is often the most accurate way to process data, as it considers the logical time when an event was produced, rather than when it was processed.
Processing Time: Processing time refers to the system time (i.e., the time when the event is processed by Flink). This is a simpler approach but can lead to inaccuracies if events are delayed.
Ingestion Time: Ingestion time refers to the time when the event enters the stream processing pipeline. This is useful when the event time is not available but can still provide some level of ordering.
Flink provides powerful mechanisms to manage time-based operations, such as watermarks, which track the progress of event time and help in handling out-of-order events.
State Management
State management is another critical aspect of stream processing. Flink allows you to maintain state across events, which is necessary for operations like rolling aggregations or more complex stateful transformations.
State Backends: Flink offers different state backends, such as RocksDBStateBackend and FsStateBackend, that store the state of an operator. These backends can store state in memory or on disk and are designed for fault tolerance and scalability.
Checkpointing: Periodic checkpointing ensures that Flink can recover from failures. Checkpoints capture the state of the application, enabling the system to restore it to a consistent point. Checkpoints are triggered at regular intervals, and Flink ensures that all operators are consistent at the checkpoint time.
Savepoints: These are manually triggered snapshots of the state, used for tasks like application upgrades or scaling. Unlike regular checkpoints, savepoints can be stored indefinitely and provide a consistent snapshot of the application's state.
Time Semantics in Stream Processing
When dealing with event-driven data in systems like Apache Flink, there are two key time concepts that are crucial for understanding event processing:
Event Time: This is the time when the event actually occurred. For example, if a system logs an event at 11:30 AM when a user purchases an item, 11:30 AM is the event time. Event time is immutable and reflects the actual occurrence of the event.
Processing Time: This refers to the time at which the event is observed by the system. For example, if an event (such as the purchase) happens at 11:30 AM but the system receives the data at 11:35 AM, then 11:35 AM is the processing time. Processing time is dynamic and changes based on when each task processes the event.
The difference between Event Time and Processing Time is known as Time Domain Skew. This skew can be caused by various factors, including network delays, system processing delays, or out-of-order data. Understanding and managing this skew is essential for accurate event processing and time-based analytics.
One tool used to visualize and manage time skew is watermarks. A watermark is a special type of event that marks the progress of event time within a stream. It provides the system with the assurance that no events with a timestamp earlier than the watermark will arrive. This allows for efficient handling of late events and provides a balance between accuracy and latency.
Eager Watermarks: These watermarks are configured to minimize latency but may sacrifice accuracy by allowing late-arriving events to be processed after the watermark.
Relaxed Watermarks: These watermarks offer higher accuracy but may increase latency because they wait for late events before moving the watermark forward.
In Flink, all events are assigned timestamps, typically representing the event time. Watermarks are also employed to help the system manage time-based operations like windowing and event-time processing. Watermarks, which are emitted along with the event stream, represent progress in event time and help synchronize the system’s event time processing.
State Management in Flink
State in Flink refers to the intermediate data that is maintained by operators throughout the lifetime of the job. State is critical because it allows the system to track computations and results based on past data. If you're unfamiliar with "state", think of it as a task variable that needs to be maintained across different input events, ensuring that the task processes the right data to produce correct results.
Types of State in Flink
Flink distinguishes between two types of state:
Operator State: This type of state is scoped to a single operator task. All records processed by the same parallel instance of the task can access and modify this state. However, tasks from different operator instances cannot access the same operator state.
Keyed State: Keyed state is associated with specific keys in the stream. Flink partitions records based on their key and ensures that all records with the same key are processed by the same operator, which has exclusive access to the state associated with that key. This type of state is particularly useful for tasks like aggregations, windowing, and session management.
State Backend in Flink
Flink offers different state backends that determine how and where the state is stored. These state backends can be configured based on the requirements of the job and include options like:
Java Heap Memory: The default backend, which stores state in the memory of the JVM heap.
RocksDB: A disk-based backend that allows state to be stored on disk and supports large-scale state handling.
Choosing the right state backend depends on the size of the state, the memory constraints, and the desired durability characteristics.
Checkpointing for Fault Tolerance
Flink provides fault tolerance through checkpointing, which periodically captures the state of the system and allows it to recover from failures. Unlike a traditional "pause, checkpoint, resume" approach, Flink's checkpointing system is designed to work without pausing the application, ensuring that data processing continues seamlessly.
The Checkpointing Process
Flink uses the Chandy-Lamport algorithm for checkpointing. When a checkpoint is initiated, the following steps occur:
The JobManager initiates a checkpoint and sends a checkpoint barrier (a special record) with a unique checkpoint ID to the source operators. This barrier indicates that the state modifications before this point belong to the current checkpoint.
Source operators stop emitting new events and checkpoint their local state to the state backend. Once done, they broadcast the checkpoint barrier to all downstream tasks.
Each downstream task that receives the checkpoint barrier waits for barriers from all its input partitions. It processes data from the partitions that haven’t received the barrier yet, while buffering data from the partition that has the barrier. This ensures that records before and after the barrier are not mixed.
After receiving barriers from all its partitions, the task checkpoints its state and broadcasts the checkpoint to its downstream tasks.
The sink task is the last task in the chain to receive all the barriers, checkpoint its state, and send an acknowledgment to the JobManager.
The JobManager considers the checkpoint successful once all tasks acknowledge the checkpoint.
This process ensures that Flink can restore to a consistent state in the event of a failure, without causing downtime or significant delays in data processing.
Conclusion
This article explored the essential concepts of time semantics, state management, and checkpointing in Flink, providing a foundation for understanding how Flink handles event-driven stream processing.
By focusing on event time vs. processing time and using watermarks to manage time skew, Flink provides an efficient way to process real-time data with accuracy and low latency. Additionally, the state management model in Flink ensures that operators can maintain and manage state across distributed systems, while checkpointing guarantees that the system can recover gracefully in the event of a failure.
I hope this article has clarified these concepts for you. If you’re interested in diving deeper into Flink or exploring other real-time processing tools, feel free to reach out or follow my upcoming articles.
Thank you for reading!
